MS-204 Insertion-Type Microwave Moisture Meter

Key Features

Rugged Construction: The entire unit is constructed of stainless steel, with key measuring points finished with special wear-resistant materials, significantly extending its lifespan.

Flexible Installation: Available with both standard threaded and flange mounting options to meet diverse application requirements (please specify the intended use when ordering).

Heat-Resistant Design: Utilizing special thermal insulation technology, it is suitable for materials typically 80°C or below, and can withstand temperatures up to 120°C, ensuring continuous and stable measurement.

Efficient Output: Response time is as fast as 500ms, and both 4-20mA analog and RS485 digital outputs are provided for easy system integration.

Key Parameters

Measurement Range: 0 - 100% Moisture

Signal Output: 4-20mA & RS485

Response Time: ≤ 500ms

Measured Object Temperature: ≤ 120°C

Product Features

FEATURE 01

Multi-Industry Applicability:

Widely used in the grain, feed, building materials, food, and beverage industries, it can measure a variety of media, including solids, liquids, and slurries.

FEATURE 02

Rugged and Durable:

Simple construction and easy installation. The rugged housing design makes it suitable for a variety of harsh industrial environments.

FEATURE 03

Stable and Maintenance-Free:

Once calibrated, it can operate continuously under stable operating conditions without frequent maintenance.

FEATURE 04

Safe and Accurate:

Adopting an intrinsically safe design, it features low voltage, low power consumption, high accuracy, and a wide measurement range.

FEATURE 05

Fast Response:

Built-in fast-response chips and high-bandwidth technology output standard signals for easy system integration.

FEATURE 06

Pressure and Corrosion Resistance:

The device's materials are heat- and corrosion-resistant, and can withstand pressures up to 4 MPa.

Product Application

Animal Feed: Various feed products.

Construction Materials: Sand and concrete for commercial concrete mixing plants.

Crops and Dried Fruits: Corn, rice, wheat, beans, etc.

Food and Beverages: Starch, protein powder, dried fruit, etc.

Environmental: Sludge, etc.

After-sales Guarantee

Provide door-to-door service (charged) and free remote service. Within one year after purchase, if there is a product quality problem caused by non-human factors, it can be replaced free of charge. If it exceeds 12 months, it can be returned to the factory for repair (under normal circumstances, the product service life is up to ten years).

Frequently Fsk Questions(FAQ)

FAQ

Q: Can the insertion microwave moisture meter measure the moisture content of sludge?

✅ A: Yes, our moisture meter is suitable for municipal sludge, industrial sludge, biomass waste, etc., with a measurement range of 5%~85%. It can monitor the dehydration or drying process in real time and optimize the processing efficiency.

Q: How to avoid highly corrosive waste from damaging the probe?

✅ A: We provide 316 stainless steel or titanium alloy probes (optional anti-corrosion coating), suitable for acidic/alkaline environments, and support automatic cleaning function to extend service life.

Q: Do you provide customized services?

✅ A: Support! The probe length, material, and communication protocol (such as wireless transmission) can be customized according to industry needs.

Q: Can the moisture content of concrete be measured? Does it affect the strength?

✅ A: Yes. Our moisture meter is suitable for fresh concrete, aggregates, gypsum boards, etc., with a measurement range of 0%~20%, non-destructive testing, and does not affect the strength of the material.

Q: The moisture content of sand and gravel fluctuates greatly, how to ensure accuracy?

A: ✅ The equipment uses multi-frequency microwave technology to automatically compensate for density and temperature changes, and can maintain high accuracy even if the moisture content of sand and gravel is in the range of 1%~15%.

Q: Can it be integrated into the mixing station automation system?

A: ✅ A: It supports 4-20mA/Modbus output and can be directly connected to the PLC system to achieve real-time moisture control of concrete mix ratio.

Q: How to prevent feed mold?

A: ✅ Real-time monitoring of the moisture content of raw materials (such as corn, soybean meal) and finished pellets (recommended ≤12%), the device supports cloud data monitoring, and automatic warning of abnormal moisture.

Q: The dust in the feed factory is large, will it affect the measurement?

A: ✅ The probe adopts a dustproof sealing design, and eliminates dust interference through a dynamic filtering algorithm, which is suitable for long-term use in feed production lines.

Q: Can it detect high-fat feed (such as fish meal)?

A: ✅ Yes. The equipment is specially calibrated for high-fat materials (fat content ≤20%) to ensure accuracy.

Q: How to avoid overdrying in dried fruit processing?

A: ✅ The equipment can be equipped with a display instrument, and the moisture threshold alarm can be set (such as raisins 15%~18%). When the moisture is lower than the set value, it will automatically remind you to avoid quality loss.

Q: What are the special requirements for moisture detection of tea?

A: ✅ Tea needs to be measured at low temperature. Our probe can work in an environment below 30℃ with an accuracy of ±0.3%.

Q: What is the insertion depth and measurement volume?

A: ✅ The standard probe insertion depth is 10~15cm, and the measurement radius is about 5cm (long-rod probes can be customized for deep materials).
